IEC60950，EN60950標準涉及的檢測項目如下：
1.1 電源接口
1.2 標記和說明
1.3 電擊和能量危險的防護
1.4 SELV電路
1.5 TNV電路
1.6 限流電路
1.7 受限制電源
1.8 接地和連接保護措施
1.9 一次電路過保護和和接地故障保護
1.10 安全聯鎖裝置
1.11 電氣絕緣
1.12 電氣間隙、爬電距離和絕緣穿透距離
1.13 導體的端接
1.14 與電網電源的連接
1.15 連接外部導線的接線端子
1.16 與電網電源的斷開
1.17 設備的互連
1.18 穩定性
1.19 機械強度
1.20 結構設計
1.21 危險的運動部件的防護
1.22 發熱要求
1.23 外殼的開孔
1.24 防火
1.25 接觸電流和保護導體電流
1.26 抗電強度
1.27 異常工作和故障條件
1.28 對通信網絡的維修人員和連接到通信網絡的其他設備的使用人員遭受設備危險的防護
1.29 對設備使用人員遭受來自通信網絡上過電壓的防護
1.30 通信配線系統的過熱保護
Delta德爾塔儀器專業致力于電子電器安全安規性能及非標定制類檢測設備系列的研發和制造，產品應用于各種家用電器（IEC/EN 60335系列, GB4706.1系列，UL60335系列）；信息技術類設備（IEC/EN60950-1, UL60950， GB4943.1），音頻/視頻及類似設備（IEC/EN60065, GB8898，UL60065）；燈具（IEC/EN 60598系列 GB7000.1系列，UL1598）；燈的控制器（整流器）（IEC/EN 61347系列, GB 19510系列，UL8750）；醫用電器設備（IEC/EN 60601系列，GB 9706.1系列，UL1993）進行功率測試，電氣強度測試，發熱試驗，絕緣電阻測試，泄漏電流測試，標簽測試，沖擊測試，電源線測試，扭力測試，推拉力測試，電氣連接和機械固定，防電擊保護測試，爬電距離和電氣間隙，防火阻燃測試，放電測試，保護裝置測試，穩定性測試，可接觸性測試，開關測試，異常操作和故障條件測試，潮濕處理，接地電阻測試，外殼防護測試等測試項目的檢測設備的提供。
IEC60950-1&GB4943.1信息技術類設備檢測實驗室儀器設備推薦清單：
SAR 測試
手機性能測試
EMC暗室測試
| 序號 | 條款號 | 檢測內容 | 所需檢測 儀器設備 | 精度要求和量程要求 | 所需檢測儀器、設備 | |||
| 設備名稱 | 設備型號 | 設備量程 | 設備精度 | |||||
| 3 | 1.6.2 | Input Current | Amp-meter | 數字功率計 | WT310 | 0—500V 0—20A 0—10kW | ±1.5% | |
| 4 | 2.1.1.1 | Access to energized parts | Test finger (joint /rigid 30N, fig. 2A) | See fig. 2A | 關節試驗指 | GS-IP100 | fig. 2A | fig. 2A |
| 5 | 直型試驗指 | GS-IP11 | fig. 2A | fig. 2A | ||||
| 6 | 推拉力計 | ANF-50 | 0—50N | ±1N | ||||
| 7 | Test pin (fig. 2B 4mm/3mm/15 mm long) | See fig. 2B | 試驗銷 | GS-IP03 | fig. 2B | fig. 2B | ||
| 8 | Test probe (fig. 2C 12mm/80mm) | See fig. 2C | 試驗探頭 | GS-IP05 | fig. 2C | fig. 2C | ||
| 9 | 2.1.1.5 | Energy Hazard | Variable resistive load | 電子負載 | 3250 | AC/DC 0-60V 0-20A 0-300W | ±1.5% | |
| 10 | 2.1.1.7 | Plug discharge | Measuring instrument with input impedance 100MΩ ±5 MΩ in parallel with an input capacitance of 25pF or less. | 示波器 | F196C | 2mV-100V/div 5ns-5s/div 100M | ±0.2% | |
| 11 | 高壓探棒 | N2771A | 0-10kV | ±1% | ||||
| 12 | 2.1.1.9 | Audio Amplifiers | Suitable signal generator and audio power measuring equipment | 噪聲信號發生器 | DF1681 | 20-20kHz 0-70dB | ±1dB | |
| 13 | 音頻信號發生器 | GAG-810 | 10-1000kHz | ±1.5% | ||||
| 14 | 2.3.1 | Limits of TNV circuits | Resistor 5000Ω ± 2%, | ±2% | 試樣電阻 | 5kΩ | 5000Ω | ±0.3% |
| 15 | 2.3.4 | Connection of TNV circuits to other circuits | Resistor 5000Ω ± 2%, | ±2% | 試樣電阻 | 5kΩ | 5000Ω | ±0.3% |
| 16 | 2.3.5 | Test for operating voltages generated externally | Test generator | 120V± 2V a.c., 50 or 60 Hz, 1200Ω ± 2% | 試驗電壓發生器 | GS-TNV10 | 0-240V 50 or 60 Hz 1200Ω | ±1% |
| 17 | 2.4.2 | Limited current circuits, limit values | Resistor 2 000 Ω ± 10%, | ± 10% | 試樣電阻 | 2kΩ | 2000Ω | ±0.5% |
| 18 | Capacitance measuring device | LCR測量儀 | 4263B | 10μH-1H 1pF-1μF 0.1Ω-100kΩ | ±0.1% | |||
| 19 | 2.6.3.4 | Resistance of earthing conductors | High current source with a voltage not exceeding 12 V | 接地電阻測試儀 | TOS6210 | 0—0.2Ω | ±0.002Ω | |
| 20 | 2.9.2 | Humidity conditioning | Chamber (91% Rh...95% Rh, 20...30 ° C) | 調溫（調濕）箱 | GS-TH800 | -40—150℃ 0-95%RH | ±2℃，±2.5%RH | |
| 21 | 2.10 | Creepage distance/clearance/distance through insulation (determination of requirements; working voltage measurements) | Oscilloscope | 示波器 | F196C | 2mV-100V/div 5ns-5s/div 100M | ±0.2% | |
| 22 | Creepagedistance/clearance/distance through insulation (measurements) | Dial gauge | 爬電距離測試卡 | CC-23 | 1.0—8.0mm | 0.1mm | ||
| 23 | Micrometer | 游標卡尺 | 150mm | 0—150mm | 0.02mm | |||
| 24 | Microscope | 讀數顯微鏡 | Vibao | 0-100mm | ±0.05mm | |||
| 25 | 2.10.3.9 | Measurement of transient levels | Test-generator; reference 2 of table N.1 | 脈沖發生器 | 1950S | 脈沖波形：1.2×50μs電壓：0-7KV | ±5% | |
| 26 | 脈沖發生器 | 1950S | 脈沖波形：10×700μs電壓：0-7KV | ±5% | ||||
| 27 | 2.10.4 | Creepage distances | Test equipment for tracking | 漏電起痕試驗裝置 | GS-TK20 | 0-600V 0-1A | ±1% | |
| 29 | 2.10.9 & 2.10.10 & 2.10.11 (and 2.10.8.2) | Thermal cycling and thermal ageing | Full draught oven (± 2oC) Cooling facility (0o C) | ± 2oC | 調溫（調濕）箱 | GS-TH800 | -40—150℃ 0-95%RH | ±2℃，±2.5%RH |
| 30 | 2.10.8.4 | Abrasion resistance test | Scratch test device with steel pin | 20mm/s; 10±0.5N, 80~85° | 耐劃痕試驗儀 | GS-NH300 | 20mm/s;10±0.5N, 80~85° | ±2% |
| 31 | 頂角40度，倒圓半徑0.25mm±0.02mm | 鋼針 | \ | 頂角40度，倒圓半徑0.25mm±0.02mm | ±1degree，±0.02mm | |||
| 32 | 2.10.7 | Enclosed and sealed parts | See 2.10.9 & 2.10.10 | ± 2oC | 調溫（調濕）箱SETH-Z-061LK | GS-TH800 | -40—150℃ 0-95%RH | ±2℃，±2.5%RH |
| 33 | 3.1.5, 3.1.9 and 4.2.2 | 10 N steady force test | Suitable tool for applying steady force of 10 N +/- 1N | ±1N | 推拉力計 | ANF-50 | 0—50N | ±1N |
| 35 | 3.2.6 | Cord anchorage and strain relief | Appropriate weights | 電源線拉扭試驗機 | GS-DXLN20 | 0-50kg | ±1% | |
| 36 | 3.2.8 | Cord guards | Appropriate weights | 推拉力計 | ANF-50 | 0—50N | ±1N | |
| 37 | 4.1 | Stability | Inclined plane 10° | 傾斜平臺 | GS-QX800 | 0-15o | ±3% | |
| 38 | Force 250N | 推拉力計 | ZP-1000 | 0-1000N | ±0.2% | |||
| 39 | Test tool 800N with a flat surface 12,5cm by 20cm | 推拉力計 | ZP-1000 | 0-1000N | ±0.2% | |||
| 40 | 金屬平面 | 136 | 12,5cm by 20cm | ±0.5% | ||||
| 41 | 4.2.3 | Steady force test 30 N | Test finger (rigid 30N± 3N, fig. 2A) | 直型試驗指 | GS-IP11 | fig. 2A | fig. 2A | |
| 42 | 推拉力計 | ANF-50 | 0—50N | ±1N | ||||
| 43 | 4.2.4 | Steady state force, 250 N | Test tool 250N± 10N with a circular plan surface ? 30mm. | 推拉力計 | ZP-1000 | 0-1000N | ±0.2% | |
| 44 | 金屬平面 | GS16 | ? 30mm | ±0.1mm | ||||
| 45 | 4.2.5 | Impact test | ? 50mm/500g± 25g steel ball | 500g± 25g | 沖擊鋼球 | GS-IP07 | 500g ? 50mm | +10g，+0.004mm |
| 46 | 4.2.6 | Drop test | Hard wood 13mm on 19mm to 20mm plywood, two layers | 跌落平臺 | GS207 | / | / | |
| 47 | 4.2.7 | Stress relief | Oven 70K over normal temp | 高溫試驗箱 | GS-GW005 | 室溫—200℃ | ±1℃ | |
| 49 | 4.2.10 | Wall or ceiling mounted equipment | Several weights | 推拉力計 | ZP-1000 | 0-1000N | ±0.2% | |
| 50 | 4.3.2 | Handles and manual controls | Force 15N/20N/30N/50N | 推拉力計 | ANF-50 | 0—50N | ±1N | |
| 51 | 4.3.6 | Direct plug-in equipment | Test equipment (see Fig. 11 of IEC 60065) | 插頭力矩測試儀 | GS-CTN04 | 0-0.25Nm | ±1% | |
| 53 | 4.3.13.2 | Ionizing radiation | Ionization meter (Annex H) | 電離輻射計 | 440RF/D | 0-1000μSV/h | ±20% | |
| 57 | 4.4 | Protection against hazardous moving parts | Test finger (joint /rigid 30N, fig. 2A) | See fig. 2A | 關節試驗指 | GS-IP100 | fig. 2A | fig. 2A |
| 58 | 直型試驗指 | GS-IP11 | fig. 2A | fig. 2A | ||||
| 59 | 推拉力計 | ANF-50 | 0—50N | ±1N | ||||
| 60 | 4.5 | Thermal requirements | ||||||
| 61 | Voltage supply | Single phase voltage supply systems/variability/adequacy | 變頻電源 | 6902 | 0-300V 0-15A | ±1.5% | ||
| 62 | Three phase voltage supply systems | 變頻電源 | AFR-360 | 60kVa | ±1.5% | |||
| 63 | Temperature (rise) | Temperature recorder (multi-channel) | 記錄儀 | DR232-02-00-1R | 0—300℃ | ±0.5℃ | ||
| 64 | Thermocouples | 熱電偶 | TT-K-30 | 0—150℃ | ±0.5℃ | |||
| 65 | Winding resistance (normally > 1,0 Ω 2-wire, 4-wire<1,0 Ω ). | 數字多用表 | 34401A | 0.1-100MΩ | ±3% | |||
| 66 | Voltage | Voltmeters (ac/dc) | 數字多用表 | 34401A | 0—1000V | ±1% | ||
| 67 | High voltage meter (probe) | 高壓探棒 | N2771A | 0-10kV | ±1% | |||
| 68 | Current | Currents (ac/dc) | 數字功率計 | WT310 | 0—500V 0—20A 0—10kW | ±1.5% | ||
| 69 | Loading | Loads (resistive) | 電子負載 | 3250 | AC/DC 0-60V 0-20A 0-300W | ±1.5% | ||
| 70 | 4.5.5 | Resistance to abnormal heat | Ball pressure test apparatus according to IEC 60695-10-2 Oven at least 125oC | 球直徑：5mm；砝碼：20N±0.2N | 球壓試驗裝置 | GS-QY21 | 球直徑：5mm；砝碼：20N | ±0.2N |
| 71 | 高溫試驗箱 | GS-GW005 | 室溫—200℃ | ±1℃ | ||||
| 72 | 4.6.2 | Bottoms of fire enclosure | Distillate fuel oil as described in Annex A.3.2 | 10ml 1ml/s | 灼熱燃油 | GS-ZRY06 | 10ml 1ml/s | ±0.2ml ±0.1ml/s |
| 73 | 4.6.4.2 | Evaluation of larger openings | Suitable tool (or tools) to simulate a straight metal object, 1mm in diameter, length up to 13 mm | ? 1mm | 試驗探針 | GS-IP14 | ? 1mm | +0.044mm |
| 74 | 4.6.5 | Adhesives for constructional purposes | Oven up to 100 ° C | 高溫試驗箱 | GS-GW005 | 室溫—200℃ | ±1℃ | |
| 75 | 4.7.3 | Materials, Tests see Annex A | V-1, V-2, HF-2, 5V | IEC60695 | 針焰試驗儀 | GS-NF30 | IEC60695 | IEC60695 |
| 76 | Bunsen burner (9,5 ± 0,5 mm) | IEC60695 | UL94水平垂直燃燒試驗儀 | GS-HVUL20 | IEC60695 | IEC60695 | ||
| 77 | Gas for burner (~37 MJ/m3) | 甲烷氣體 | 98%純度以上 | / | / | |||
| 78 | Oven for preconditioning | 高溫試驗箱 | GS-GW005 | 室溫—200℃ | ±1℃ | |||
| 79 | 4.7.3.6 | Materials used in high-voltage components | Test of Annex A or test of 14.4 of IEC 60065 or needle flame test according to IEC 60695-2-2 | IEC60695 | 針焰試驗儀/水平垂直燃燒儀 | GS-NF30\GS-HVUL20 | IEC60695 | IEC60695 |
| 80 | 5.1 | Touch current and protective conductor current | Measuring instruments of Annex D | 泄漏電流測試儀 | Simpson228 | 0-10mA | ±1% | |
| 81 | 5.2 | Electric strength | Test equipment with the relevant voltage and tripping current | 短路電流>200mA | AC/DC耐壓絕緣測試儀 | TOS9201 | AC:0-5kV， 0—110mA; DC:0-6kV, 0-10mA; 短路電流>200mA | ±1% |
| 83 | 6.2.1 | Protection of equipment users from overvoltages on telecommunication networks | Test probe (Fig. 2C, 12mm/80mm) | See fig. 2C | 試驗探頭 | GS-IP05 | fig. 2C | fig. 2C |
| 84 | 6.2.2.1 | Impulse Test | Impulse test generator according to Annex N | 脈沖發生器 | 1950S | 脈沖波形：10×700μs電壓：0-7KV | ±5% | |
| 85 | 6.2.2.3 | Protection of equipment users from overvoltages on telecommunication networks | insulation resistance | 絕緣電阻測試儀 | TOS7200 | 0-1000V 0-2000MΩ | ±0.5% | |
| 86 | 7.4.2 | Voltage surge test | Test generator reference 3 of table N.1 | 浪涌測試儀 | SUG10/700G | 0-10kV | ±5% | |
| 87 | 7.4.3 | Impulse test | Test generator reference 1 of table N.1 | 脈沖發生器 | 1950S | 脈沖波形：10×700μs電壓：0-7KV | ±5% | |
